Mercedes Liposuction Cannula, 2 to 5 mm

What a Mercedes liposuction cannula is

A Mercedes liposuction cannula is a hollow steel tube with a closed, rounded end and three ports cut in a ring just behind it. The surgeon passes it through a small incision into the fat layer, a syringe or a suction line pulls on the back end, and fat enters through the ports as the cannula moves. The trade calls that ring of three the Mercedes pattern and the cannula a Mercedes tip cannula, and it is the starting point the rest of the family is measured against.

What makes the pattern useful is where the ports face. One port draws from one side of the shaft only. Three spaced around the tip draw from every side at once, so the surgeon does not have to hold the cannula turned a particular way to keep it working. That is why it gets used for general debulking, and for harvesting fat that is going back in somewhere else as a graft.

We sell this tip three ways: here with a choice of hub, with the handle fixed on, and as a cannula for a power assisted handpiece. This page is the first of the three.

Key design features

Three ports in one ring

The three ports sit in a single ring a short way behind the tip, spaced evenly around the shaft. Each is an elongated slot rather than a round hole, which is how the pattern shows in our own photograph of this cannula. A slot gives tissue a longer opening to enter than a round hole of the same width, and three of them around the shaft are what let a Mercedes cannula keep working whichever way it is rotated in the hand.

A closed, rounded tip

The end of the tube is closed and rounded. A blunt end is the norm on an aspiration cannula, because the instrument is meant to move through fat rather than cut a path of its own. A cannula built for fibrous tissue has a different tip, and we list those separately.

Seven ways to finish the back end

The order form offers seven ways to finish the back end: a super fix handle in style A or style B, an aluminum Luer lock, a steel Luer lock, a super Luer lock, a Toomey hub, or a threaded fitting. The Luer lock hubs screw onto a syringe or onto a separate Luer handle, and the Toomey hub takes a 60 cc Toomey syringe for harvesting by hand. The two super fix handles turn the cannula into one piece for a suction line, and the threaded fitting screws into a handle made to take it. The hub also sets the price: 22 dollars with either Luer lock, 32 with the super Luer lock or the threaded fitting, 37 with the Toomey hub, and 45 or 55 with a super fix handle.

A straight shaft in five diameters

The shaft is straight, and it comes in 2, 2.4, 3, 4 and 5 mm. Lengths run from 15 to 35 cm. A short shaft is easier to control in a small area, and a long one reaches across an abdomen or a thigh from one incision.

Which size to order

The order form offers five diameters and lengths from 15 to 35 cm, but not every length at every diameter. This is the whole list, read off our own order form on 21 October 2026. Which sizes you can pick also depends on the hub, and the form shows only the sizes that go with the hub you have chosen.

Where it is used

Five Google AI Mode answers for this family, taken on 21 October 2026, name these uses. They describe how surgeons use the pattern, not anything we measured. The last column is ours.

What it is for, and what it is not for

A Mercedes cannula is a general pattern, which makes it easy to reach for out of habit. These are the jobs where something else in our range does the work better.

How it compares with the rest of the family

Five patterns make up this family on our site. The names are the trade’s, and the second column says what each name means on the tip. The last column is read off each product’s own order form, so it is the size range you can actually buy.

Materials and finish

Every Mercedes cannula we make is formed from high quality medical grade stainless steel. The steel itself is made to a German specification. We do not publish a grade number.

Each port is cut through the wall of the tube, and its edges are what tissue passes over on the way in. On the aluminum Luer lock the hub is aluminum, and on the steel Luer lock it is steel.

Caring for it

Flush the cannula with water as soon as it comes out of use, before anything dries in the lumen. Push a cannula brush through the full length, and clean each port from the outside as well. Fat and blood dried inside a narrow tube are hard to see and harder to shift. Dry it, then steam sterilize it on the normal instrument cycle. Store it flat or hanging straight, because a bent shaft no longer runs true in the tissue.

Ordering and wholesale

The Mercedes liposuction cannula is made by Adas Instruments in our own workshop and sold direct, which is why the price sits where it does against the catalog houses. Order one for a single tray, or in quantity for a hospital list or a distributor line. We do OEM work under your own brand and your own item numbers. Send us a sample and we will hold a run to your pattern rather than ours. Stock items ship from our own workshop. Backorder items take 10 to 12 working days to make. Every instrument carries a three year replacement warranty against manufacturing defects. Production is controlled under an ISO 13485 quality management system.

Frequently asked questions

What is a Mercedes liposuction cannula used for?

It is used to remove fat during body contouring and to harvest fat for grafting. The three ports spaced around the tip draw from every side, so the stroke keeps working whichever way the cannula is turned. That is why it suits larger areas such as the abdomen and thighs as well as smaller ones.

How much does a Mercedes liposuction cannula cost?

The base price is 32 dollars, and the hub moves it up or down. The aluminum or steel Luer lock brings it to 22 dollars, the Toomey hub to 37, and the super fix handles to 45 or 55, as the hub section above sets out. Every cannula carries our three year replacement warranty against manufacturing defects.

What size Mercedes cannula should I order?

That depends on the area and on how much is coming out, and it is the surgeon’s call rather than ours. What we can tell you is what we make: 2, 2.4, 3, 4 and 5 mm, in lengths from 15 to 35 cm. The 2 mm comes only in 15 and 18 cm, and the 5 mm only in 25, 30 and 35 cm. The size table above has every combination.

Which hub should I choose?

Choose the one that matches what is already on your tray. If you aspirate with a syringe, take a Luer lock, or the Toomey hub for a 60 cc Toomey syringe. If the cannula goes on a suction line, a super fix handle makes it one piece. If you already own a handle that takes a threaded shaft, take the threaded fitting.

How is a Mercedes liposuction cannula different from a double Mercedes?

A Mercedes carries one ring of three ports. A double Mercedes carries two rings, which is six ports and more open area on each pass. Our double Mercedes is made in 3 to 5 mm and 25 to 35 cm, a narrower range than the single Mercedes, which starts at 2 mm and 15 cm. Both take the same seven hub choices.

Related products and categories

Three more patterns from the same family: double Mercedes liposuction cannula, triple Mercedes liposuction cannula and two lateral one central hole liposuction cannula. The whole range is in aspiration cannulas, and the handles, adapters and sets that go with it are under liposuction cannulas and accessories.
