Freeman Face Lift Retractor Small, 10 cm, 22 mm Head, Thumb Ring
$ 18.00
Freeman face lift retractors in the small size, often classified as a Freeman mini rake retractor, are the short version of the Freeman flap rake, 10 cm long with a 22 mm head. A thumb ring is built into the handle, and that ring is the point of the pattern: it lets one hand hold and angle the retractor on its own while the other hand keeps the scissors. It is used in mini and short scar facelifts and in secondary facelift surgery, on thin facial skin flaps and periauricular skin.
Key Features
- 10 cm overall with a 22 mm head, both from our own record
- A thumb ring in the handle for one handed control
- Four sharp in line prongs on a short shaft
- Cut for tight pockets where the full 18 cm instrument will not sit
- Used on thin facial skin flaps, periauricular skin and subcutaneous planes
- High quality medical grade stainless steel, autoclavable and made to be used again
- Three year replacement warranty against manufacturing defects
Available on backorder
What the freeman face lift retractor small is
The freeman face lift retractor small is the short member of the Freeman rake family. Our own record gives it as 10 cm overall with a 22 mm head, against about 18 cm for the standard instrument, and most catalogs file it under a second name, the mini rake retractor.
The length is only half the story. The other half is the thumb ring built into the handle, which turns a two handed instrument into a one handed one. With a ring, the assistant can hold the flap, change the angle of pull and let go of nothing, and the surgeon gets to keep both hands on the scissors.
That combination, short shaft and ring, is why this pattern exists as a separate item rather than as a size option on the standard retractor.
Key design features of this mini rake retractor
Four things define it, and three of them follow from the first.
- 10 cm overall. Short enough to work inside a pocket the full length instrument cannot enter without lifting the flap higher than you want to.
- A 22 mm head. The narrow width of the family, placed accurately rather than broadly.
- A thumb ring in the handle. One handed control, and the instrument stays put if the hand relaxes.
- Four sharp in line prongs. An even pull across a thin flap, which is the tissue this size is usually working on.
Freeman face lift retractor small size
Both figures below come from our own product record, which is the reason this table is short and certain.
| What | Figure | Where it comes from | Item code |
|---|---|---|---|
| Overall length | 10 cm | Our own product record | AP-65.21 |
| Head width | 22 mm | Our own product record | AP-65.21 |
| Handle | Thumb ring | Our own product record | |
| Prongs | 4 sharp, in line | Family standard, not carried as an attribute in our record | |
| Product attributes | None on file | A gap in our own data, stated here rather than filled in |
What our record does not carry is a product attribute table, so there is no separate entry confirming prong count or handle finish. The 10 cm and the 22 mm are ours. Anything past that is made to order and will be measured on request.
Where a mini rake retractor is used
A mini rake retractor earns its place in the cases where reach is the problem, not strength.
| Specialty | What the freeman face lift retractor small is used for |
|---|---|
| Mini facelift | Short flaps in a small pocket, where the full length rake will not sit |
| Short scar facelift | Working through a limited incision |
| Secondary facelift | Scarred planes that are shallow and will not accept a wide head |
| Periauricular dissection | Thin skin in front of and behind the ear |
| Facial reconstruction | Small flaps raised and held one handed |
| Eyelid and brow surgery | Fine flap traction where reach is measured in centimeters |
| Assisting single handed | Any step where the second hand is already holding something else |
What the prongs hold, and what they do not
A short instrument with sharp points has a narrower brief than the full size version, and the limits are worth stating.
| Structure | How the prongs take it |
|---|---|
| Thin facial skin flaps | What the pattern is for. Four points, even pull, low tension per hold |
| Periauricular skin | Held during the part of a facelift where the flap is at its thinnest |
| Subcutaneous tissue | Engaged on the deep surface |
| Small reconstructive flaps | Held one handed while the other hand sutures |
| A full length facelift flap | NOT this one. Use the standard 18 cm instrument |
| Deep neck planes | NOT this one. Too short, and prongs are the wrong answer that deep |
| Mucosa and vessels | NOT this instrument, at any size |
How the freeman mini rake retractor compares with the rest of the family
Five of the six rows are our own instruments. The first row is the one that matters most, because the difference between the two Freeman rakes is length and a ring, nothing else.
| Pattern | How it differs | When you reach for it instead |
|---|---|---|
| Freeman face lift retractor | About 18 cm, 22 or 36 mm head, flat handle, no ring | The open part of the flap, where reach matters more than a ring |
| Freeman face lift retractor Adamson model | A wide head on an offset bend | Lifting a large flap in one bite |
| Freeman flap retractor | A smooth blade rather than prongs | A flap that must not be pierced |
| Biggs face lift retractor | One broad fenestrated blade | Deep, broad, blunt traction |
| Ferreira face lift retractor | A narrow right angled blade, often lit | A narrow channel rather than an open flap |
| Skin hook | One or two prongs on a fine shaft | A skin edge rather than a flap |
Materials and finish
Made from high quality medical grade stainless steel, satin finished so the operating light does not reflect off the shaft. The steel itself is made to a German specification. The inside edge of the thumb ring is rolled rather than left square, because a ring that is worn against a thumb through a long case will mark it if the edge is sharp.
Care and sterilization
Clean with a soft brush under running water, working between the prongs and around the inside of the ring where glove debris collects, then rinse in deionized water and dry fully before autoclaving. Store on a rack or under a tip guard. Check that the ring is still round: a ring bent out of shape stops fitting the thumb, and a retractor that has to be gripped instead of worn has lost the only thing that separates it from the standard pattern.
Ordering and wholesale
Adas Instruments makes this pattern to order and supplies hospitals, surgical centers and distributors across the United States, Latin America, Europe and Asia. Item code AP-65.21. Bulk and wholesale pricing is available, and instruments held on backorder ship in 10 to 12 working days. Every instrument carries a three year replacement warranty against manufacturing defects. Certifications: CE. Production is controlled under an ISO 13485 quality management system.
Frequently asked questions
What is a freeman face lift retractor small used for?
Holding a thin facial skin flap back in a pocket too tight for the full length rake. It is used in mini and short scar facelifts, in secondary facelift surgery where the planes are scarred and shallow, and around the ear where the flap is thinnest.
Is a freeman face lift retractor small the same as a mini rake retractor?
Yes. Mini rake retractor is the name most catalogs use for this size, and it describes the head better than the word small does. Both names point at the same 10 cm instrument with a 22 mm head.
What does the thumb ring actually do?
It lets one hand do the whole job. Without a ring, holding a retractor at a fixed angle is a pinch grip, and a pinch grip tires within minutes and then drifts. With a ring, the load sits on the thumb and the forearm, the angle can be changed by rotating the wrist, and the instrument does not fall out of position if the grip relaxes.
Is the freeman face lift retractor small long enough for a full facelift?
Not on its own. Most sets carry the 10 cm and the full length instrument together and change between them as the flap is raised, starting long where the plane is open and moving to the short one as the dissection runs into the corners.
How many prongs does it have?
Four sharp prongs, in line. Our own product record does not carry a prong count as an attribute, which is worth saying plainly, so the figure here is the family standard and is confirmed on request before a bulk order.
Related products and categories
Buyers who order the freeman face lift retractor small usually order alongside it the freeman face lift retractor adamson model, the freeman flap retractor and the biggs face lift retractor. The whole family sits in hooks and retractors, and this pattern is also listed under facelift and neck lift instruments.
