Kleinert Kutz Elevator Dissector, Double Ended

What the Kleinert Kutz elevator is

The Kleinert kutz elevator is a hand instrument used to lift fine soft tissue and periosteum off small bone. Surgeons also call it a double ended Kleinert Kutz elevator, a Kleinert Kutz elevator dissector or an elevator Kleinert Kutz. It is made by Adas Instruments in high quality medical grade stainless steel, and it is reusable and fully autoclavable.

It is the elevator build in the Kleinert Kutz family, double ended and slim, and it leads with lifting a sheet of periosteum off small bone rather than opening a fascial plane.

The work an elevator does is always the same in principle. A layer of soft tissue is stuck to the cartilage or bone under it, and it has to come off in one sheet without a hole in it. Get that right and the rest of the case has a dry field and a flap that will lie back down. That is why the shape of the working end and the stiffness of the blade decide which pattern a surgeon picks up.

Key design features of the Kleinert Kutz elevator

• Double ended elevator, a working end at each end of one shaft
• Slim enough for the small bones of the hand and wrist
• Blunt working ends that lift a sheet rather than cutting it
• Turned in the hand, which matters most when the field is small
• Flat knurled handle in the middle for a pencil grip
• High quality medical grade stainless steel, reusable and autoclavable

The handle is flat and knurled rather than round. A flat handle tells you where the blade is facing without looking at it, and the knurling holds when a glove is wet. The shaft runs straight into the blade with no step, so there is no shoulder to catch on the rim of a nostril and nothing for protein to sit in after a case.

Kleinert Kutz elevator sizes and build options

The build below is the one we ship. Overall length is confirmed on the quotation rather than printed here, because this pattern is made to order for OEM runs and the shaft length is set by the run.

Nothing is listed above that we do not hold. If a build you need is not in the table, ask, because a pattern like this is often made to order for an OEM run and a change of size is a tooling change rather than a new instrument.

Uses of the Kleinert Kutz elevator by specialty

The Kleinert Kutz elevator appears on the same trays across these specialties because the job is the same one each time, lifting a tissue plane cleanly off what lies under it.

The specialty name and the procedure name are both worth knowing when you order, because catalogues file this pattern under whichever of the two the buyer used. An operating room manager searches by procedure and a purchasing office searches by specialty, and they are looking for the same instrument.

Tissue planes the Kleinert Kutz elevator works in

An elevator handles no suture and no needle. What decides the choice of pattern is the plane it has to open and how much force that plane takes.

Force is the part nobody writes down. Perichondrium on young cartilage lifts with almost nothing, while mucoperiosteum on bone needs a firm push and a stiff blade behind it. Match the blade to the plane and the instrument does the work instead of your wrist.

How the Kleinert Kutz elevator compares with other patterns

These four sit next to each other on a hand tray and they are not interchangeable.

Surgeons who use this pattern usually also hold the Kleinert Kutz dissector, the Read periosteal elevator double ended and the Tessier periosteal elevator. The closest relative in the range is the Kleinert Kutz dissector.

If you are building a tray from scratch, the usual answer is two elevators rather than one. Something light for cartilage and something stiffer for bone covers almost every case.

Materials and finish

The instrument is made in high quality medical grade stainless steel. The steel itself is made to a German specification. The blade is flat ground and satin finished, which cuts glare under the lights in an operating room and keeps the working end readable against wet tissue. There is no coating to chip and nothing on the shaft to trap protein.

Stainless steel is chosen here for a reason that has nothing to do with appearance. An elevator is levered, and a levered instrument that is too hard will crack at the neck while one that is too soft will take a set and stay bent. The grade used sits between the two.

Kleinert kutz elevator care and sterilization

Rinse the instrument in cool water straight after use so blood does not dry on the blade. Clean it with a soft brush and a neutral pH enzymatic detergent, rinse in deionized water, then dry it completely. Steam autoclave at 134 degrees Celsius. Lay it in the tray so the blades do not rest against other instruments, because a bruised edge on an elevator is what tears a flap.

Look at the working end against the light before every case. A blunt end should be smooth with no flat spot and no nick, and a working edge should still sit flat on bone. An elevator that has been dropped on a tiled floor is the one that buttonholes a flap two cases later, and it costs nothing to check.

Ordering and wholesale

This pattern is supplied by Adas Instruments to hospitals, surgical distributors and OEM buyers, in single units and in bulk. The item code is AN-58.07 and it is printed in the size table above so a procurement search finds it. Backorder items dispatch in 10 to 12 working days. Every instrument carries a three year replacement against manufacturing defects.

For wholesale and OEM orders, instruments ship unpackaged in bulk or individually poly bagged, and laser marking with a distributor code or a hospital asset number is available on the shaft. Tell us the quantity and the marking you need and the quotation comes back with the lead time for that run rather than a stock figure.

Production is controlled under an ISO 13485 quality management system. The instrument is CE marked.

Frequently asked questions

What is a Kleinert Kutz elevator used for?

It lifts periosteum and fine soft tissue off the small bones of the hand and wrist. A sheet that comes off whole can be laid back down, and on a phalanx there is very little of it, which is why the pattern is built this thin.

Is the Kleinert Kutz elevator double ended?

Yes. A double ended Kleinert Kutz elevator carries a working end at each end of one shaft, and in a field a finger wide that saves the plane every time the width changes.

How is an elevator Kleinert Kutz different from the dissector build?

They are the two builds in the same family, this one AN-58.07 and the dissector AN-58.08. Quote the item code on your preference card and we will match it.

Does it work outside hand surgery?

Yes, anywhere a small bone needs a sheet of periosteum lifted cleanly, which includes some plastic surgery and microsurgery cases, but hand and upper extremity work is where it earns its place on the tray.

How do you clean and sterilize a Kleinert Kutz elevator dissector?

Rinse in cool water straight after use, clean with a soft brush and a neutral pH enzymatic detergent, rinse in deionized water, dry fully, then steam autoclave at 134 degrees Celsius.
